Cube 625 - H.264(AVC) Decoder SDI/HDMI GbE - Refurbished
Product Highlights
- Real-Time H.264 (AVC) Decoder
- Ethernet and USB Interfaces (No WiFi)
- HDMI and SDI Video Outputs (Outputs 1080p/30)
- Camera Top Form Factor
- Built-In Scaler
- OLED Display
- Powers by AC Adapter or 2-pin Connector Battery
- Outfitted for 1/4" Mounting
Price: $1,300.00
Deposit:$1,300.00
$1,890.00 USD
Overview
*Refurbished item may show signs of gentle use that do not affect product function. All items will be quality tested before shipment.*
Professional, scalable integrated decoder designed for video over IP delivery. Compatible with Cube encoders, Cube 625 offers SD/HD MPEG-4 AVC decoding for point-to-point video distribution, allowing content creators, broadcasters and system integrators to cost-effectively and reliably meet strict QoS requirements.
With flexible HDMI/3G-SDI dual-output and Ethernet/WiFi (2.4/5Ghz)/cellular USB connection options, Cube 625 streamlines IP video deployment in existing workflows and enhances infrastructure for all users. Small form factor and high-performance decoding make it one of the most versatile solutions for content delivery strategies in the video ecosystem.
What's In The Box?
Support
FAQs
Downloads
Technical Specifications
Click on each category to see the relevant tech specs OR click this button:
Video +
Video Outputs
- • HDMI 1.4a: Full Size
- • SD/HD/3G-SDI (75 Ω BNC)
Supported Resolutions +
Supported Resolutions
- • 1080p 23.98/24/25/29.97/30/50/59.94/60*
- • 1080i 50/59.94/60
- • 1080PsF 23/24/25/29/30
- • 720p 50/59.94/60
- • 576i
- • 480i
- • 480p (for HDMI output only)
- • 576p (for HDMI output only)
Video Processing +
Video Compression
- • Decompresses H.264, Baseline, Main and High Profile
Supported Video Bitrate
- • 250 Kbps to 15 Mbps*
- • *15 Mbps (wired), 10 Mbps (WiFi)
Test Pattern Generator Support
- • None
Video Format Conversion Support
- • Built in Video Scaler and Deinterlacer
Color Correction
- • None
Protocol Support +
Network Protocols
- • TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP
Supported Video Transport Protocols
- • RTP/RTSP: Unicast/TCP, Unicast/UDP, Multicast/UDP streams
- • MPEG Transport Stream: Unicast/TCP (pushed in from an external source, or pulled down from a remote server such as Core), Unicast/UDP, Multicast/UDP
- • Teradek Streaming : Unicast/UDP, Multicast/UDP
Remote Control
- • Teradek Core
Audio Processing +
Audio Compression
- • AAC-LC, MPEG Layer 2
Inputs +
Audio Input
- • Embedded Audio Input
- • Analog Line or Mic in, adjustable gain
Outputs +
Audio Output
- • Headphone output, adjustable volume
Physical +
Dimensions
- • 4.75"W x 3"D x 1.1"H [120.7 x 76.2 x 27.9mm]
Weight
- • 11.6oz [328.9g]
Construction
- • Milled Aluminum
Interfaces +
Http
- • WebUI for Configuration and Control
Configuration Interfaces
- • OLED Display with joystick Navigation buttons
- • Feature-rich WebUI for configuration and control
Switches
- • On/Off and Reset Switch
Mobile App
- • Vuer, Live:Air
Usb Interface Functionality
- • Powered USB 2.0 host port
Network +
Ethernet
- • 10/100BASE-T
Wireless
- • None
Usb
- • None
Power +
Power Input
- • 2 Pin Connector Power input
Battery
- • No Battery Included
Nominal Power Consumption
- • 8W, 7W (no WiFi)
Auxilary Power Input
- • 6-28V DC
